XT90 Battery Cable with JST SMR & 6.35mm Terminal | EV Wiring Harness

xt90 battery cable with 6.35mm 250 terminal and signal connector

xt90 battery wiring harness with jst smr connector for electric vehicle

xt90 connector detail on high current battery cable

jst smr connector on battery wiring harness for signal control

PRODUCT PARAMETERS

This XT90 battery wiring harness is designed for electric vehicles, lithium battery packs, and electric scooters requiring both power and signal connections. It features a high-current XT90 connector for main power transmission, a JST SMR connector for signal control, and a 6.35mm (250) terminal for secure and stable electrical connection.

The combination of power and signal connectors makes this cable ideal for complex EV battery systems, ensuring efficient energy transfer and reliable communication between components.

Built with high-quality wires and durable insulation, this wiring harness offers excellent flexibility, heat resistance, and long-term performance in demanding environments.

Custom length, wire gauge, and connector configurations are available to meet different application needs.

REQUEST A QUOTE

Description

FAQs

Request A Quote

Description

XT90 Battery Wiring Harness with JST SMR Connector for Electric Vehicles

XT90 High Current Battery Cable for EV Power Systems

XT90 connector designed for high current transmission

Provides stable and secure power connection

Suitable for electric scooters and lithium battery packs

JST SMR Connector for Signal and Control Wiring

JST SMR connector for signal transmission

Ensures reliable communication in BMS systems

Compact design for multi-wire connections

6.35mm (250) Terminal for Reliable Power Connection

Standard 6.35mm (250) terminal for strong contact

Widely used in EV battery connections

Easy to install and maintain

XT90 Battery Wiring Harness Features and Advantages

Integrated power and signal wiring harness design

Suitable for electric vehicles and electric scooters

Durable insulation for long-term performance

Flexible and easy to install

Custom cable length and wire gauge available

Applications for Electric Scooter and EV Battery Systems

Electric scooter battery wiring harness

Electric vehicle (EV) battery systems

Lithium battery pack connections

Energy storage systems

FAQs

What types of products can we offer?

What logistics do we ship through?

Can it be customized as per our requirements?

What is our ordering process?

Send Drawing / Requirements

Engineering Assistance—Since most of the cost decisions are made during the design phase, we can help you make component choices to limit future cost issues.

Rapid Prototyping (3-7Days)—Our teams will respond quickly and closely with you, your team, and your project to help you optimize the form, fit, and function of your harness or cable assembly. They will also make you aware of opportunities to reduce costs, while still achieving comparable or greater quality.

Sample Approval

Mass production

Quality Inspection & Delivery

Whether in terms of application, function, construction type, material selection or connection method, customized wiring harnesses can provide targeted solutions to meet special working environments and performance requirements.
